| Cutting Diameter (DC) | 12 mm | Corner Radius (RE) | 2 mm |
| Connection Diameter Machine Side (DCONMS) | 16 mm | Neck Diameter (DN) | 11.7 mm |
| Depth of Cut Maximum (APMX) | 18 mm | Body Half Taper Angle (BHTA) | 0.9 Degrees |
| Overall Length (OAL) | 130 mm | Peripheral Effective Cutting Edge Count (ZEFP) | 4 |
| Coating | AlTiCrN | Length Group | Taper Neck |
| End Shape | Corner Radius | Measurement Type | Metric |
| Usable Length (LU) | 21 mm | Series/List # | VFHVRB_TAPER_NECK |
Product Features
| Country of Origin | JP |
Shipping Info
Package Weight
.9999
