| Thread Diameter Size (TDZ) | #10 | Standard | 302 |
| Threads per Inch (TPI) | 24 | Chamfer | 4P-5P |
| Thread Standard | UNF | Coating | Uncoated |
| Overall Length (OAL) | 6″ | End Shape | Plug |
| Thread Cutting Part Length (THL) | 0.88″ | Coolant Supply Property (CSP) | External |
| Usable Length (LU) | 0.88″ | Measurement Type | Wire Gauge |
| Connection Diameter Machine Side (DCONMS) | 0.194″ | Flute Type | Spiral Point |
| Flute Count (NOF) | 2 | Series/List # | T7236 |
| Cutting Edge Material | HSS | Thread Size | #10 - 24 |
| Thread Tolerance Class (TCTR) | H3 | Shank Type | Square |
| Tool Type | General Purpose |
Product Features
| Country of Origin | KR |
Shipping Info
Package Length
6.375
Package Width
0.5
Package Height
0.5
Package Weight
0.053
